Brief Introduction
Brand
Product model
SBS-SRT-FG

Model numberSBS-SRT-FG

Working Temperature-60-200

Structure

It is extruded by food grade level silicone rubber.

Usage

Food Grade Silicone Rubber Tubing are commonly used in contact with foods in accordance with provisions of FDA 21 CFR 177.2600. It can be installed in Coffee maker, Drinking fountains, Hookah and Home appliances waterproof line protection.

Specification

Performance

Test method

Performance index

Tearing strengthMPa

ASTM D 2671

25 MPa

Elongation%

ASTM D 2671

300%

Flame retardant

UL224

VW-1

Breakdown strength (kv/mm)

IEC 60243

26

Volume resistivity(Ω/cm

IEC 60093

1014

Copper corrosion

UL 224

Passed

Water absorption

ASTM D 570

< 0.1%

Dimension

Performance

Test method

Performance index

Tearing strengthMPa

ASTM D 2671

25 MPa

Elongation%

ASTM D 2671

300%

Flame retardant

UL224

VW-1

Breakdown strength (kv/mm)

IEC 60243

26

Volume resistivity(Ω/cm

IEC 60093

1014

Copper corrosion

UL 224

Passed

Water absorption

ASTM D 570

< 0.1%

Dimension

Inner Diameter(mm)

Tolerancemm

Thickness and tolerance (mm)

Φ2.0

±0.10

1.00 ±0.10

Φ3.0

±0.10

1.50 ±0.10

Φ4.0

±0.10

2.00±0.10

Φ5.0

±0.10

2.00±0.10

Φ6.0

±0.10

2.00±0.10

Φ8.0

±0.10

2.00±0.10

Φ8.0

±0.10

2.70±0.10

Φ9.0

±0.10

2.50±0.10



 RemarkOther sizes can be made upon customer requirements.
